Min.Working  length

500mm

Working  thickness

2-100/150mm

Sanding roller diameter

240mm

Polishing roller diameter

300mm

Polishing roller speed

Frequency

Feeding  speed

2.5-12.5m/min

Total  motor  power

39.34kw

Overall dimensions

4100*2100*2100mm

Net weight

5200kg

Sanding motor power

22kw

Disk motor power

1.5KW*2

Spiral roller motor power

3KW *3

Lifting motor

0.37KW*5

Workbench lift motor

0.55KW

Conveying motor

2.2KW

Swing motor

0.37KW *2
