Max.working width

1300mm

Min.working length

360mm

Working thickness

2.0-100mm

Speed

5-25m/min] Can be adjusted

Total power

27.12kw(11,11,4，0.75,0.37)

First frame power

11kw

Second frame power

11kw

Transport belt power

4kw

Up and down motor power

0.75kw

Brush motor power

0.73kw

First sanding speed

3-16m/s Can be adjusted

Second sanding speed

3-16m/s Can be adjusted

Fist rubber roll diameter

∮240mm  SH20-23°

Second rubber roll diameter

∮240mm  SH20-23°

Sanding belt size

1320mm×2200mm

Air pressure

0.6Mpa

Amount of dust

9600m³/h

Voltage

415V/50HZ/3Phase

Electric parts

Schneider

Machine size

2700×2100×2100mm

Net weight

4000kg
